2605 Series SAE# 070424 / MS# 51511
| PART NO.SIZE |
TUBE O.D. |
B1 SAE 37 |
A2 NPFT |
B3 SAE 37 |
B1 DRILL |
A2 DRILL |
B3 DRILL |
M1 LGTH |
L LGTH |
M2 LGTH |
Y FLATS |
| 2605-03-02-03-FG |
3/16 |
3/8-24 |
1/8-27 |
3/8-24 |
0.125 |
0.188 |
0.125 |
0.83 |
0.72 |
0.83 |
0.438 |
| 2605-04-02-04-FG |
1/4 |
7/16-20 |
1/8-27 |
7/16-20 |
0.172 |
0.188 |
0.172 |
0.89 |
0.78 |
0.89 |
0.438 |
| 2605-04-04-04-FG |
1/4 |
7/16-20 |
1/4-18 |
7/16-20 |
0.172 |
0.281 |
0.172 |
1.05 |
1.09 |
1.05 |
0.562 |
| 2605-05-02-05-FG |
5/16 |
1/2-20 |
1/8-27 |
1/2-20 |
0.234 |
0.188 |
0.234 |
0.95 |
0.78 |
0.95 |
0.562 |
| 2605-05-04-05-FG |
5/16 |
1/2-20 |
1/4-18 |
1/2-20 |
0.234 |
0.281 |
0.234 |
1.05 |
1.09 |
1.05 |
0.562 |
| 2605-06-02-06-FG |
3/8 |
9/16-18 |
1/8-27 |
9/16-18 |
0.297 |
0.188 |
0.297 |
1.06 |
0.90 |
1.06 |
0.562 |
| 2605-06-04-04-FG |
3/8 |
9/16-18 |
1/4-18 |
7/16-20 |
0.297 |
0.281 |
0.172 |
1.06 |
1.09 |
1.05 |
0.562 |
| 2605-06-04-06-FG |
3/8 |
9/16-18 |
1/4-18 |
9/16-18 |
0.297 |
0.281 |
0.297 |
1.06 |
1.09 |
1.06 |
0.562 |
| 2605-06-06-06-FG |
3/8 |
9/16-18 |
3/8-18 |
9/16-18 |
0.297 |
0.406 |
0.297 |
1.14 |
1.22 |
1.14 |
0.750 |
| 2605-06-08-06-FG |
3/8 |
9/16-18 |
1/2-14 |
9/16-18 |
0.297 |
0.531 |
0.297 |
1.22 |
1.47 |
1.22 |
0.875 |
| 2605-08-04-08-FG |
1/2 |
3/4-16 |
1/4-18 |
3/4-16 |
0.391 |
0.281 |
0.391 |
1.25 |
1.22 |
1.25 |
0.750 |
| 2605-08-06-06-FG |
1/2 |
3/4-16 |
3/8-18 |
9/16-18 |
0.391 |
0.406 |
0.297 |
1.25 |
1.22 |
1.14 |
0.750 |
| 2605-08-06-08-FG |
1/2 |
3/4-16 |
3/8-18 |
3/4-16 |
0.391 |
0.406 |
0.391 |
1.25 |
1.22 |
1.25 |
0.750 |
| 2605-08-08-06-FG |
1/2 |
3/4-16 |
1/2-14 |
9/16-18 |
0.391 |
0.531 |
0.297 |
1.25 |
1.47 |
1.22 |
0.875 |
| 2605-08-08-08-FG |
1/2 |
3/4-16 |
1/2-14 |
3/4-16 |
0.391 |
0.531 |
0.391 |
1.33 |
1.47 |
1.33 |
0.875 |
| 2605-08-12-08-FG |
1/2 |
3/4-16 |
3/4-14 |
3/4-16 |
0.391 |
0.719 |
0.391 |
1.42 |
1.59 |
1.42 |
1.062 |
| 2605-10-08-10-FG |
5/8 |
7/8-14 |
1/2-14 |
7/8-14 |
0.484 |
0.531 |
0.484 |
1.45 |
1.47 |
1.45 |
0.875 |
| 2605-10-12-10-FG |
5/8 |
7/8-14 |
3/4-14 |
7/8-14 |
0.484 |
0.719 |
0.484 |
1.54 |
1.59 |
1.54 |
1.062 |
| 2605-12-08-12-FG |
3/4 |
1-1/16-12 |
1/2-14 |
1-1/16-12 |
0.609 |
0.531 |
0.609 |
1.66 |
1.59 |
1.66 |
1.062 |
| 2605-12-12-08-FG |
3/4 |
1-1/16-12 |
3/4-14 |
3/4-16 |
0.609 |
0.719 |
0.391 |
1.66 |
1.59 |
1.42 |
1.062 |
| 2605-12-12-12-FG |
3/4 |
1-1/16-12 |
3/4-14 |
1-1/16-12 |
0.609 |
0.719 |
0.609 |
1.66 |
1.59 |
1.66 |
1.062 |
| 2605-14-12-14-FG |
7/8 |
1-3/16-12 |
3/4-14 |
1-3/16-12 |
0.719 |
0.719 |
0.719 |
1.80 |
1.69 |
1.80 |
1.312 |
| 2605-16-12-16-FG |
1 |
1-5/16-12 |
3/4-14 |
1-5/16-12 |
0.844 |
0.719 |
0.844 |
1.81 |
1.78 |
1.81 |
1.312 |
| 2605-16-16-16-FG |
1 |
1-5/16-12 |
1-11-1/2 |
1-5/16-12 |
0.844 |
0.938 |
0.844 |
1.81 |
1.97 |
1.81 |
1.312 |
| 2605-20-16-20-FG |
1-1/4 |
1-5/8-12 |
1-11-1/2 |
1-5/8-12 |
1.078 |
0.938 |
1.078 |
2.06 |
2.35 |
2.06 |
1.625 |
| 2605-20-20-16-FG |
1.-1/4 |
1-5/8-12 |
1-1/4-11-1/2 |
1-5/16-12 |
1.078 |
1.250 |
0.844 |
2.06 |
2.38 |
2.01 |
1.625 |
| 2605-20-20-20-FG |
1-1/4 |
1-5/8-12 |
1-1/4-11-1/2 |
1-5/8-12 |
1.078 |
1.250 |
1.078 |
2.06 |
2.38 |
2.06 |
1.625 |
| 2605-24-24-24-FG |
1-1/2 |
1-7/8-12 |
1-1/2-11-1/2 |
1-7/8-12 |
1.312 |
1.500 |
1.312 |
2.33 |
2.64 |
2.33 |
1.875 |
| 2605-32-32-32-FG |
2 |
2-1/2-12 |
2-11-1/2 |
2-1/2-12 |
1.781 |
1.938 |
1.781 |
3.06 |
3.00 |
3.06 |
2.500 |
