2606 Series SAE# 070426 /MS# 51514
| PART NO.SIZE |
TUBE O.D. |
B1 SAE 37 |
A2 NPTF |
B3 SAE 37 |
B1 DRILL |
B3 DRILL |
M LGTH |
L LGTH |
N LGTH |
Y FLATS |
| 2606-03-02-03-FG |
3/16 |
3/8-24 |
1/8-27 |
3/8-24 |
0.125 |
0.125 |
1.03 |
0.66 |
1.03 |
0.562 |
| 2606-04-02-04-FG |
1/4 |
7/16-20 |
1/8-27 |
7/16-20 |
0.172 |
0.172 |
1.08 |
0.66 |
1.08 |
0.562 |
| 2606-04-04-04-FG |
1/4 |
7/16-20 |
1/4-18 |
7/16-20 |
0.172 |
0.172 |
1.22 |
0.88 |
1.22 |
0.750 |
| 2606-05-02-05-FG |
5/16 |
1/2-20 |
1/8-27 |
1/2-20 |
0.234 |
0.234 |
1.08 |
0.66 |
1.08 |
0.562 |
| 2606-05-04-05-FG |
5/16 |
1/2-20 |
1/4-18 |
1/2-20 |
0.234 |
0.234 |
1.22 |
0.88 |
1.22 |
0.750 |
| 2606-06-04-06-FG |
3/8 |
9/16-18 |
1/4-18 |
9/16-18 |
0.297 |
0.297 |
1.23 |
0.88 |
1.23 |
0.750 |
| 2606-06-06-04-FG |
3/8 |
9/16-18 |
3/8-18 |
7/16-20 |
0.297 |
0.172 |
1.31 |
1.02 |
1.29 |
0.875 |
| 2606-06-06-06-FG |
3/8 |
9/16-18 |
3/8-18 |
9/16-18 |
0.297 |
0.297 |
1.31 |
1.02 |
1.31 |
0.875 |
| 2606-08-06-08-FG |
1/2 |
3/4-16 |
3/8-18 |
3/4-16 |
0.391 |
0.391 |
1.42 |
1.02 |
1.42 |
0.875 |
| 2606-08-08-08-FG |
1/2 |
3/4-16 |
1/2-14 |
3/4-16 |
0.391 |
0.391 |
1.52 |
1.23 |
1.52 |
1.062 |
| 2606-10-08-10-FG |
5/8 |
7/8-14 |
1/2-14 |
7/8-14 |
0.484 |
0.484 |
1.64 |
1.23 |
1.64 |
1.062 |
| 2606-12-12-12-FG |
3/4 |
1-1/16-12 |
3/4-14 |
1-1/16-12 |
0.609 |
0.609 |
1.89 |
1.36 |
1.89 |
1.312 |
| 2606-14-12-14-FG |
7/8 |
1-3/16-12 |
3/4-14 |
1-3/16-12 |
0.719 |
0.719 |
1.86 |
1.42 |
1.86 |
1.312 |
| 2606-16-16-16-FG |
1 |
1-5/16-12 |
1-11-1/2 |
1-5/16-12 |
0.844 |
0.844 |
2.17 |
1.62 |
2.17 |
1.625 |
| 2606-20-20-20-FG |
1-1/4 |
1-5/8-12 |
1-1/4-11-1/2 |
1-5/8-12 |
1.078 |
1.078 |
2.23 |
1.70 |
2.33 |
1.875 |
| 2606-24-24-24-FG |
1-1/2 |
1-7/8-12 |
1-1/2-11-1/2 |
1-7/8-12 |
1.312 |
1.312 |
2.89 |
2.08 |
2.89 |
2.562 |
