FS7215 Series
| PART NO.SIZE |
TUBE O.D. |
A1 THREAD |
B THREAD |
A2 THREAD |
A1 DRILL |
B DRILL |
A2 DRILL |
M1 LGTH |
N LGTH |
M2 LGTH |
C HEX |
JJ FLATS |
| FS7215-04-12-04-NWO-FG |
1/4 |
9/16-18 |
M12 x 1.5 |
9/16-18 |
4.5 |
4.0 |
4.5 |
21.5 |
33.0 |
21.5 |
17 |
14 |
| FS7215-04-14-04-NWO-FG |
1/4 |
9/16-18 |
M14 x 1.5 |
9/16-18 |
4.5 |
6.0 |
4.5 |
23.5 |
35.5 |
23.5 |
19 |
17 |
| FS7215-06-14-06-NWO-FG |
3/8 |
11/16-16 |
M14 x 1.5 |
11/16-16 |
6.5 |
6.0 |
6.5 |
25.0 |
35.5 |
25.0 |
19 |
17 |
| FS7215-06-16-06-NWO-FG |
3/8 |
11/16-16 |
M16 x 1.5 |
11/16-16 |
6.5 |
7.0 |
6.5 |
25.0 |
37.5 |
25.0 |
22 |
17 |
| FS7215-08-14-08-NWO-FG |
1/2 |
13/16-16 |
M14 x 1.5 |
13/16-16 |
9.5 |
6.0 |
9.5 |
28.0 |
36.0 |
28.0 |
19 |
19 |
| FS7215-08-18-08-NWO-FG |
1/2 |
13/16-16 |
M18 x 1.5 |
13/16-16 |
9.5 |
9.0 |
9.5 |
28.0 |
41.0 |
28.0 |
24 |
19 |
| FS7215-08-22-08-NWO-FG |
1/2 |
13/16-16 |
M22 x 1.5 |
13/16-16 |
9.5 |
12.0 |
9.5 |
31.0 |
49.0 |
31.0 |
27 |
24 |
| FS7215-10-18-10-NWO-FG |
5/8 |
1-14 |
M18 x 1.5 |
1-14 |
12.5 |
9.0 |
12.5 |
33.5 |
47.5 |
33.5 |
24 |
24 |
| FS7215-10-22-10-NWO-FG |
5/8 |
1-14 |
M22 x 1.5 |
1-14 |
12.5 |
12.0 |
12.5 |
33.5 |
49.0 |
33.5 |
27 |
24 |
| FS7215-12-27-12-NWO-FG |
3/4 |
1-3/16-12 |
M27 X 2.0 |
1-3/16-12 |
15.5 |
15.0 |
15.5 |
37.5 |
55.5 |
37.5 |
32 |
27 |
| FS7215-16-33-16-NWO-FG |
1 |
1-7/16-12 |
M33 X 2.0 |
1-7/16-12 |
20.5 |
20.0 |
20.5 |
41.5 |
59.5 |
41.5 |
41 |
36 |
| FS7215-20-42-20-NWO-FG |
1-1/4 |
1-11/16-12 |
M42 X 2.0 |
1-11/16-12 |
26.0 |
26.0 |
26.0 |
44.5 |
63.0 |
44.5 |
50 |
41 |
| FS7215-24-48-24-NWO-FG |
1-1/2 |
2-12 |
M48 X 2.0 |
2-12 |
32.0 |
32.0 |
32.0 |
49.0 |
71.5 |
49.0 |
55 |
50 |
