RHV-R-ED
| Type Designation |
SERIES |
PN bar(psi) |
Tube OD |
G |
kg per 100St. Kg per 100pcs. Kg par 100p. |
d |
L2 |
L5 |
l |
i |
S1 |
S2 |
S3 |
Øentspr. Durchla beta Øoutlet Øde passage correspondant |
| RHV 6 LR-ED |
L |
400(5801) |
6 |
G 1/8 A |
12.0 |
13.9 |
50.5 |
43 |
36 |
8 |
22 |
14 |
27 |
4.0 |
| RHV 8 LR-ED |
L |
400(5801) |
8 |
G 1/4 A |
12.0 |
18.9 |
50.5 |
43 |
36 |
12 |
22 |
17 |
27 |
6.0 |
| RHV 10 LR-ED |
L |
400(5801) |
10 |
G 1/4 A |
11.5 |
18.9 |
48.5 |
41 |
34 |
12 |
22 |
19 |
27 |
6.0 |
| RHV 12 LR-ED |
L |
400(5801) |
12 |
G 3/8 A |
14.0 |
21.9 |
53.5 |
46 |
39 |
12 |
22 |
22 |
27 |
7.5 |
| RHV 15 LR-ED |
L |
400(5801) |
15 |
G 1/2 A |
19.0 |
26.9 |
56 |
48 |
41 |
14 |
27 |
27 |
32 |
11.0 |
| RHV 18 LR-ED |
L |
400(5801) |
18 |
G 1/2 A |
23.0 |
26.9 |
61.5 |
53 |
45.5 |
14 |
27 |
32 |
32 |
11.0 |
| RHV 22 LR-ED |
L |
250(3626) |
22 |
G 3/4 A |
47.0 |
31.9 |
69.5 |
61 |
53.5 |
16 |
41 |
36 |
46 |
18.0 |
| RHV 28 LR-ED |
L |
250(3626) |
28 |
G 1 A |
52.5 |
39.9 |
77 |
68 |
60.5 |
18 |
41 |
41 |
46 |
20.0 |
| RHV 35 LR-ED |
L |
250(3626) |
35 |
G 1 1/4 A |
137.0 |
49.9 |
88.5 |
77.5 |
67 |
20 |
60 |
50 |
70 |
29.0 |
| RHV 42 LR-ED |
L |
250(3626) |
42 |
G 1 1/2 A |
140.0 |
54.9 |
87.5 |
75.5 |
64.5 |
22 |
60 |
60 |
70 |
29.0 |
| RHV 6 SR-ED |
S |
400(5801) |
6 |
G 1/4 A |
13.0 |
18.9 |
52.5 |
45 |
38 |
12 |
22 |
17 |
27 |
4.0 |
| RHV 8 SR-ED |
S |
400(5801) |
8 |
G 1/4 A |
12.0 |
18.9 |
50.5 |
43 |
36 |
12 |
22 |
19 |
27 |
5.0 |
| RHV 10 SR-ED |
S |
400(5801) |
10 |
G 3/8 A |
13.5 |
21.9 |
53.5 |
45 |
37.5 |
12 |
22 |
22 |
27 |
7.5 |
| RHV 12 SR-ED |
S |
400(5801) |
12 |
G 3/8 A |
14.5 |
21.9 |
55.5 |
47 |
39.5 |
12 |
22 |
24 |
27 |
7.5 |
| RHV 14 SR-ED |
S |
400(5801) |
14 |
G 1/2 A |
19.5 |
26.9 |
59.5 |
50 |
42 |
14 |
27 |
27 |
32 |
10.0 |
| RHV 16 SR-ED |
S |
400(5801) |
16 |
G 1/2 A |
23.0 |
26.9 |
62.5 |
53 |
44.5 |
14 |
27 |
30 |
32 |
11.0 |
| RHV 20 SR-ED |
S |
400(5801) |
20 |
G 3/4 A |
59.5 |
31.9 |
74 |
63 |
52.5 |
16 |
41 |
36 |
46 |
16.0 |
| RHV 25 SR-ED |
S |
250(3626) |
25 |
G 1 A |
54.0 |
33.9 |
77 |
65 |
53 |
18 |
41 |
46 |
46 |
20.0 |
| RHV 30 SR-ED |
S |
250(3626) |
30 |
G 1 1/4 A |
86.0 |
49.9 |
87 |
74 |
60.5 |
20 |
50 |
50 |
55 |
24.0 |
| RHV 38 SR-ED |
S |
250(3626) |
38 |
G 1 1/2 A |
144.1 |
54.9 |
96 |
81.5 |
65.5 |
22 |
60 |
60 |
70 |
29.0 |
