2503 Series SAE# 070302 / MS# 51508
| PART NO.SIZE |
TUBE O.D. |
B1 SAE 37 |
A2 NPTF |
B1 DRILL |
A2 DRILL |
M LGTH |
L LGTH |
Y FLATS |
| 2503-02-02-FG |
1/8 |
5/16-24 |
1/8-27 |
0.062 |
0.188 |
0.69 |
0.52 |
0.438 |
| 2503-03-02-FG |
3/16 |
3/8-24 |
1/8-27 |
0.125 |
0.188 |
0.69 |
0.52 |
0.438 |
| 2503-04-02-FG |
1/4 |
7/16-20 |
1/8-27 |
0.172 |
0.188 |
0.72 |
0.64 |
0.438 |
| 2503-04-04-FG |
1/4 |
7/16-20 |
1/4-18 |
0.172 |
0.281 |
0.82 |
0.86 |
0.562 |
| 2503-04-06-FG |
1/4 |
7/16-20 |
3/8-18 |
0.172 |
0.406 |
0.85 |
0.95 |
0.750 |
| 2503-04-08-FG |
1/4 |
7/16-20 |
1/2-14 |
0.172 |
0.531 |
0.87 |
1.17 |
0.875 |
| 2503-05-02-FG |
5/16 |
1/2-20 |
1/8-27 |
0.234 |
0.188 |
0.77 |
0.64 |
0.562 |
| 2503-05-04-FG |
5/16 |
1/2-20 |
1/4-18 |
0.234 |
0.281 |
0.82 |
0.86 |
0.562 |
| 2503-05-06-FG |
5/16 |
1/2-20 |
3/8-18 |
0.234 |
0.406 |
0.85 |
0.95 |
0.750 |
| 2503-06-02-FG |
3/8 |
9/16-18 |
1/8-27 |
0.297 |
0.188 |
0.83 |
0.67 |
0.562 |
| 2503-06-04-FG |
3/8 |
9/16-18 |
1/4-18 |
0.297 |
0.281 |
0.83 |
0.86 |
0.562 |
| 2503-06-06-FG |
3/8 |
9/16-18 |
3/8-18 |
0.297 |
0.406 |
0.87 |
0.95 |
0.750 |
| 2503-06-08-FG |
3/8 |
9/16-18 |
1/2-14 |
0.297 |
0.531 |
0.88 |
1.17 |
0.875 |
| 2503-06-12-FG |
3/8 |
9/16-18 |
3/4-14 |
0.297 |
0.719 |
0.93 |
1.20 |
1.062 |
| 2503-08-04-FG |
1/2 |
3/4-16 |
1/4-18 |
0.391 |
0.281 |
0.98 |
0.95 |
0.750 |
| 2503-08-06-FG |
1/2 |
3/4-16 |
3/8-18 |
0.391 |
0.406 |
0.98 |
0.95 |
0.750 |
| 2503-08-08-FG |
1/2 |
3/4-16 |
1/2-14 |
0.391 |
0.531 |
0.99 |
1.17 |
0.875 |
| 2503-08-12-FG |
1/2 |
3/4-16 |
3/4-14 |
0.391 |
0.719 |
1.04 |
1.20 |
1.062 |
| 2503-10-04-FG |
5/8 |
7/8-14 |
1/4-18 |
0.484 |
0.281 |
1.11 |
0.98 |
0.875 |
| 2503-10-06-FG |
5/8 |
7/8-14 |
3/8-18 |
0.484 |
0.406 |
1.11 |
0.98 |
0.875 |
| 2503-10-08-FG |
5/8 |
7/8-14 |
1/2-14 |
0.484 |
0.531 |
1.11 |
1.17 |
0.875 |
| 2503-10-12-FG |
5/8 |
7/8-14 |
3/4-14 |
0.484 |
0.719 |
1.16 |
1.20 |
1.062 |
| 2503-12-08-FG |
3/4 |
1-1/16-12 |
1/2-14 |
0.609 |
0.531 |
1.28 |
1.20 |
1.062 |
| 2503-12-12-FG |
3/4 |
1-1/16-12 |
3/4-14 |
0.609 |
0.719 |
1.28 |
1.20 |
1.062 |
| 2503-12-16-FG |
3/4 |
1-1/16-12 |
1-11-1/2 |
0.609 |
0.938 |
1.42 |
1.48 |
1.312 |
| 2503-14-12-FG |
7/8 |
1-3/16-12 |
3/4-14 |
0.719 |
0.719 |
1.45 |
1.30 |
1.312 |
| 2503-16-08-FG |
1 |
1-5/16-12 |
1/2-14 |
0.844 |
0.531 |
1.47 |
1.29 |
1.312 |
| 2503-16-12-FG |
1 |
1-5/16-12 |
3/4-14 |
0.844 |
0.719 |
1.47 |
1.29 |
1.312 |
| 2503-16-16-FG |
1 |
1-5/16-12 |
1-11-1/2 |
0.844 |
0.938 |
1.47 |
1.48 |
1.312 |
| 2503-16-20-FG |
1 |
1-5/16-12 |
1-1/4-11-1/2 |
0.844 |
1.250 |
1.54 |
1.67 |
1.625 |
| 2503-20-16-FG |
1-1/4 |
1-5/8-12 |
1-11-1/2 |
1.078 |
0.938 |
1.59 |
1.64 |
1.625 |
| 2503-20-20-FG |
1-1/4 |
1-5/8-12 |
1-1/4-11-1/2 |
1.078 |
1.250 |
1.59 |
1.67 |
1.625 |
| 2503-20-24-FG |
1-1/4 |
1-5/8-12 |
1-1/2-11-1/2 |
1.078 |
1.500 |
1.65 |
1.77 |
1.875 |
| 2503-24-20-FG |
1-1/2 |
1-7/8-12 |
1-1/4-11-1/2 |
1.312 |
1.250 |
1.78 |
1.74 |
1.875 |
| 2503-24-24-FG |
1-1/2 |
1-7/8-12 |
1-1/2-11-1/2 |
1.312 |
1.500 |
1.78 |
1.77 |
1.875 |
| 2503-32-32-FG |
2 |
2-1/2-12 |
2-11-1/2 |
1.781 |
1.938 |
2.22 |
2.11 |
2.500 |
| 2503-40-40-FG |
2-1/2 |
3-8 |
2 1/2-8 |
2.318 |
2.318 |
2.49 |
2.20 |
3.234 |
