| PART NO.SIZE | TUBE O.D. | A FORB | B THREAD | B DRILL | L LGTH | C HEX |
|---|---|---|---|---|---|---|
| FS6410-04-04-O | 1/4 | 7/16-20 | 9/16-18 | 0.172 | 1.09 | 0.688 |
| FS6410-08-08-O | 1/2 | 3/4-16 | 13/16-16 | 0.378 | 1.36 | 1.062 |
| FS6410-16-12-O | 1 | 1-5/16-12 | 1-3/16-12 | 0.609 | 1.79 | 1.625 |
| FS6410-16-16-O | 1 | 1-5/16-12 | 1-7/16-12 | 0.811 | 1.80 | 1.625 |
| FS6410-20-20-O | 1-1/4 | 1-5/8-12 | 1-11/16-12 | 1.024 | 1.86 | 2.125 |
| FS6410-24-24-O | 1-1/2 | 1-7/8-12 | 2-12 | 1.260 | 1.87 | 2.500 |
